2 Axis Force & Torque Sensor | DBBSS/TSF

The DBBSS/TSF series of dual axis force and torque sensors are a compact and accurate transducer designed to measure both static torque and axial load in tension and/or compression.

The unique design of the 2 axis force and torque sensor ensures that crosstalk between the axes is minimised, with less than 1% being typical, whilst maintaining an excellent accuracy of better than 0.1% of rated capacity in both torque and force modes.

The DBBSS/TSF 2 axis force and torque sensor series is used widely in the geotechnical and materials testing sectors where it is employed as a central component on pieces of high accuracy analytical test equipment, although its design lends itself to a huge range of other applications where dual-axis measurement is required.

The nature applications where the 2 axis force and torque sensor may be used is likely to require customisation in terms of size, capacity and the configuration of mounting holes or fixtures, and so we are pleased to say that design modifications to fit the DBBSS/TSF to your application can be offered with little or no effect on cost.

Send us your enquiry using the form below, or call us on +44 (0) 1189 817339 and we will be happy to help.

Datasheet

Associated Products

     TR150 Handheld Digital Indicator
     Intuitive2-L Panel-Mount Indicator
    T24 Wireless Telemetry Range
     DSC-USB USB Signal Digitiser
     ICA Miniature Strain Gauge Amplifier
     SGA Signal Conditioner/Amplifier

Quick Enquiry Form

• Capacities: 0-1kN/0-10Nm to 0-250kN/0-2500Nm

• Output: 1.5-3.0mV/V

• Accuracy: <±0.1%/RC

• Environmental Protection: IP65

• Custom Versions Available
