Miniature S-Beam Load Cell | DBCR

The DBCR series of miniature S-Beam load cells are suitable for use in both tension and compression and lend themselves to a multitude of low-range monitoring, control, test and measurement applications including material testing machines and small suspended hoppers.

The DBCR is a compact version of the classic S-Beam load cell design manufactured from aluminium in ranges of 0-10N and 0-20N and 17-4PH stainless steel in ranges from 0-50N to 0-500N and offers a very high accuracy of better than 0.05% of rated capacity.

The DBCR S-Beam load cell can be supplied calibrated with any of our range of strain gauge input instrumentation to provide a complete, ready to use measurement system.

For other sizes and capacities please view our full range of S-Beam load cells.

Datasheet

Mounting Accessories

Rod-End Bearings & Load Buttons

Associated Products

     TR150 Handheld Digital Indicator
     Intuitive2-L Panel-Mount Indicator
    T24 Wireless Telemetry Range
     DSC-USB USB Signal Digitiser
     ICA Miniature Strain Gauge Amplifier
     SGA Signal Conditioner/Amplifier

Quick Enquiry Form

• Capacities: 0-10N up to 0-500N

• Output: 2mV/V

• Environmental Protection: IP65

• Accuracy: <±0.05%/RC

• Compact Size
