Miniature In-Line Tension & Compression Load Cell | DDE

The DDE series of miniature in-line load cells are suitable for use in both tension and compression and offer a very low profile body coupled with integral mounting threads to allow their use in applications with restricted mounting space where other in-line load cell designs such as S-Beam load cells are too large.

The DDE's small size means that weight is kept to a minimum, this, in conjunction with it's low deflection, results in a high stiffness assembly and makes the load cell suited to the measurement of fast changes in load and high frequency transients.

The DDE miniature in-line load cell is currently being used in many applications including automotive production, cable tension monitoring and suspension force monitoring.  Customised versions with different thread sizes, specific dimensions and interim capacity can also provided if required.

Datasheet

Associated Products

     TR150 Handheld Digital Indicator
     Intuitive2-L Panel-Mount Indicator
    T24 Wireless Telemetry Range
     DSC-USB USB Signal Digitiser
     ICA Miniature Strain Gauge Amplifier
     SGA Signal Conditioner/Amplifier

Quick Enquiry Form

• Capacities: 0-100N up to 0-50kN

• Output: 2mV/V

• Environmental Protection: IP65

• Accuracy: <±0.25%/RC

• Low Profile Design
