Waterproof Torque Sensor | DRWPL

The DRWPL series of waterproof torque sensors are rated to IP67 and have been specially designed for operation in harsh environments.  They will operate happily where dust, water and high humidity are present constantly, and will even withstand short-term immersion to less than 1 metre depth for 30 minutes maximum.

A ±10Vdc analogue output is provided from DRWLP's internal signal conditioner which offers a 200Hz frequency response.  Pulsed speed and angle output options are also available.

Customised couplings can be offered with the DRWPL torque sensor to ensure straightforward integration into your application along with optimum performance.

Please contact our expert sales team using the form below, call us on +44 (0) 1189 817339, or send an email to info@appmeas.co.uk and we will be happy to assist you with your enquiry.

Datasheet

Associated Products

     Intuitive2-P Panel-Mount Indicator
     Tracker 211 Panel-Mount Indicator
    T24 Wireless Telemetry Range

Quick Enquiry Form

• Primary Capacities: 0-0.1Nm to 0-1500Nm

• ±10Vdc Output

• Non-Linearity: <±0.1%/Rated Capacity

• Max Speed: 1900 to 20,000rpm

  (depending on capacity)

• Specially Designed Couplings


• Optional Speed & Angle Outputs
