Intrinsically Safe Pressure Sensor (ATEX) | P642FAX

The P642FAX range of ATEX Certified, Intrinsically Safe pressure sensors are designed for use in hazardous areas across all common industrial applications.

The P642FAX intrinsically safe pressure transmitter has a Titanium media connection offering compatibility with a wide range of harsh and aggressive pressure media.

The pressure sensor's electrical output is the intrinsically safe standard 4-20mA, 2-wire signal, connection to which is made via a DIN43650 plus & socket.  Pressure connection is made via a G¼" male on pressure ranges up to 700bar, while a high pressure F-250-C Autoclave fitting is supplied thereafter.

If you require your intrinsically safe pressure transmitter to be supplied with suitable barriers please contact us with the details of your requirement and we will be pleased to source and supply them.

Datasheet

Associated Products

     Intuitive2-P Panel-Mount Indicator

Quick Enquiry Form

• Ranges: 0-0.5bar up to 0-2500bar

• Outputs: 4-20mA

• ATEX Certified: II 1GD EEx ia IIC T4

                         Ex iaD 20 T200ºC

                         Ta = -20ºC to +70ºC

                         Intrinsically Safe

• Environmental Protection: IP65

• Accuracy: <±0.25%/FS
