Low Differential Pressure Sensor | PR3202

The PR3202 low differential pressure sensor is designed for the measurement of dry, non-corrosive gases across range of general purpose and industrial applications such as HVAC, clean room monitoring and flow measurement applications.

The PR3202 low differential pressure transmitter utilises a highly stable sensing element which allows it's 4-20mA output to be factory-scaled over measuring ranges as small as 0-0.25mbar (0-25 Pascals).

In addition to differential pressure, the PR3202 can also measure gauge and vacuum / suction pressure, it can also operate bi-directionally giving the ability to measure compound differential pressure ranges that range from vacuum to positive pressure.

The PR3202 low range differential pressure sensor's process connection is made via hose fittings which cater for common mode / line pressures of up to 10bar.

Contact us now with your enquiry using our quick form below, or call our expert sales team on +44 (0) 1189 817339 to discuss your requirement.

Datasheet

Associated Products

     Intuitive2-P Panel-Mount Indicator
     Tracker 211 Panel-Mount Indicator
    T24 Wireless Telemetry Range

Quick Enquiry Form

• Ranges: 0-0.25mbar up to 0-1000mbar

• Outputs: 4-20mA

• Line / Common Mode Pressure: 10bar max.

• Accuracy: <±0.25%/FS

• Optional ATEX Intrinsically Safe Version

  (minimum range 0-5mbar, 4-20mA only)
