Ring Torsion Load Cell | Bending Ring Load Cell | CTUS

The CTUS series of low profile ring torsion load cells are suitable for high capacity compression measurement and weighing applications where a low-height assembly is desirable such as vessels, silos and weighbridges.

The ring torsion measuring principle employed in the bending ring load cell design provides excellent accuracy to 0.02% of rated capacity, it also enables the load cell to be hermetically sealed via fully-welded construction providing IP68 sealing.

The high level of sealing and stainless steel construction the ring torsion load cell is ideal for use in process situations where regular washdowns are required to maintain hygiene standards.

In addition to high accuracy, the ring torsion load cell also offers excellent thermal stability characteristics to cater for applications where temperature variations are commonplace.  This is complimented by excellent long term stability.

We offer two different mounting assemblies to provide straightforward installation and optimal performance of all of our ring torsion load cell models, one caters for silo and vessel weighing applications and the other is designed for weighbridge use.  Customised mounts can also be offered if required, please send us an enquiry or call our technical sales team on 01189 817339.

Datasheet

Mounting Accessories

Silo Mount    Weighbridge Mount

Associated Products

     Intuitive2-L Panel-Mount Indicator
     SGA Signal Conditioner/Amplifier
    AMLJBNA 4-Way Passive Junction Box
    T24 Wireless Telemetry Range

Quick Enquiry Form

• Capacities: 0-5000kg up to 0-50,000kg

• Output: 2mV/V

• Environmental Protection: IP68

• High Accuracy: <±0.02%/RC

  (<±0.05%/RC on 50,000kg version)

• ATEX Version Available
